Fluoropolymer-insulated Heating Cable up to 260 °C

Fluoropolymer-insulated Heating Cable up to 260 °C

Application

Vessels, piping, valves
Small components
Industrial areas
Rotor blades
Marble plates

Standard

DIN VDE 0253

Voltage Rating

750V

Construction

Heating conductor.
Insulation: Fluoropolymer.

Mechanical and Thermal Properties

Maximum operating temperature: 260℃
Minimum installation temperature: -60℃
Minimum bending radius: 2.5xOD
Maximum output: 30 W/m
Nominal resistance of heating conductor: 8000 Ω/km

Cable Parameter

Nominal resistance Ω/km APPROX. outer diameter mm 7APPROX. weight g/m Temperature coefficient x 10¯³/K
1.95 5.8 112 4.3
2.90 4.6 73 4.3
4.40 4.2 54 4.3
7.20 3.1 33 4.3
10.0 3.0 31 4.3
11.7 2.7 30 4.3
15.0 2.6 19 4.3
25.0 2.5 17 3.0
31.5 2.9 23 1.6
50.0 2.6 17 1.6
65.0 2.4 14 0.9
80.0 2.7 20 0.9
100.0 2.5 17 0.45
157.0 2.5 17 0.45
180.0 2.2 12 0.90
200.0 2.4 14 0.45
260.0 2.2 12 0.45
280.0 2.1 10 0.38
328.0 2.5 16 0.18
360.0 2.1 10 0.45
430.0 2.3 13 0.18
480.0 2.2 12 0.18
600.0 2.1 10 0.18
800.0 2.0 9 0.18
1000.0 2.1 10 0.04
1470.0 2.1 9 0.04
1750.0 2.0 8 0.04
1900.0 2.2 12 0.04
2900.0 2.1 9 0.04
4000.0 2.0 8 0.04
4700.0 1.9 8 0.15
6000.0 1.9 7 0.20
7000.0 2.0 7 0.15
8000.0 2.0 7 0.15
