BS 6346 Standards PVC Insulated Cables,1900/3300V
Single-core 1900/3300 V cables with solid aluminum conductor

Application

These cables are used for power and control circuits, they can offer excellent protection through the use of a heavy galvanized steel wire armour, so they are well adapted to underground use in industrial applications, in moist areas.

Construction

Conductor Solid Aluminum or Copper conductor, round stranded or shaped, Class 2 to BS 6460, IEC 60228. Insulation PVC(Polyvinyl Chloride) type TI1

Colour Code 1 Core : Brown
  2 Cores: Brown, Blue
  3 Cores: Brown, Black, Grey 4 Cores: Blue, Brown, Black, Grey 5 Cores: Green-yellow, Blue, Brown, Black, Grey Above 5 Cores: White Cores with black numbers
Filler(optional) Binder Tape(optional) Inner Sheath/ Bedding Armour Outer Sheath PVC or Polypropylene yarn Polyester (Mylar) tape PVC (Polyvinyl Chloride) Single Core: AWA (Aluminum WireArmour) Multi Core: SWA (Steel Wire or Tape Armour) PVC(Polyvinyl Chloride), type TM1

Technical Information

Voltage rating 1900/3300V
Temperature rating -20°C to +60°C
Bending radius Single core: 10 x overall diameter     Multicores: 8 x overall diameter
Flame retardant IEC60332 part 1, BS4066 part 1

Single-core 1900/3300 V cables with solid aluminum conductor

Nominal cross-sectional area Nominal insulation thickness Nominal bedding thickness Nominal alum wire armor dia. Nominal sheath thickness Approx. overall diameter Approx. cable weight
mm² mm mm mm mm mm kg/mm
1x50 2.2 0.8 1.25 1.6 19.8 625
1x70 2.2 0.8 1.25 1.6 21.3 735
1x95 2.2 1.0 1.6 1.7 24.3 965
1x120 2.2 1.0 1.6 1.7 25.6 1090
1x150 2.2 1.0 1.6 1.8 27.1 1250
1x185 2.2 1.0 1.6 1.8 28.8 1415
1x240 2.2 1.0 1.6 1.9 31.2 1680
1x300 2.4 1.0 1.6 1.9 33.7 1935
